Applications:

• For stitching extra heavy-weight materials.
• Designed for such operations and products as safety and logging belts, cargo slings, buffing wheels, tents, sails, harnesses, tarpaulins and covers, fabric structures, construction barriers, parachutes, balloons, industrial bags, boot stitching, book binding.

Features:

• Synchronized upper and lower feeding mechanism assures uniform stitching
• Alternating presser feet
• Steel insert for take-up hinge
• Reverse stitching – hand or foot operated
• Stitch regulator – hand or foot operated
• 1-1/4 inch presser foot lift
• Tow row feeder
• Two stitches to the inch
• Stitches per minute – 550
• Extra large, long-beak oscilating shuttle, hook and bobbin
• Belt guard

Specifications:

• Speed, Max. (S.P.M.): 550
• Clearance Under Foot: 1-1/4″ (25.4 mm)
• Needle Bar Stroke: 2-3/32″ (53 mm)
• Stitch Length, Max. 2 s.p.i. (13 mm)
• Needle: 1000 or 10000H
• Bobbin:
  • Metal: 35226
  • Pre-wound: 41
• Hook: 35224
• Bed Size: 10″ x 26-1/4″ (258 x 655 mm)
• Work Space: 16-1/4″ (413 mm)
• Stitch Type: 301
• Weight: 231 lbs. (205 kg.)
