Applications:

• For sewing medium to heavy-weight materials such as canvas, vinyl, leather, synthetics and various coated, laminated materials.
• Designed for stitching such products as overalls, raincoats, luggage, travelware accessories, bags, umbrellas, awnings, covers, tarpaulins, tents, wearing apparel, outdoor clothing, underwear, etc.
• Suitable for stitching uneven, hollow, tubular and curved articles.
• Also for secondary operations on finished articles such as attaching braids, pockets, tapes, etc.

Features:

• Compound feed, walking foot mechanism assures perfect feeding of sewing material
• Large hooks and bobbin cases
• Centra-Lube® semi-automatic lubrication system
• Stitches per minute – 2400 *
• Reverse stitching
• Various gauge sets available
• Safety clutch prevents the hook from being damaged

Specifications:

• Speed, Max. (S.P.M.): 2400 *
• Clearance Under Foot:
  • 11/32″ (8.5 mm) hand
  • 7/16″ (11 mm) foot
• Needle Bar Stroke: 1-5/16″ (33 mm)
• Stitch Length, Max. 4.2 s.p.i. (6 mm)
• Needle: 135 x 17
• Bobbin:
  • Metal: 10541
  • Pre-wound: U
• Hook: 14505
• Bed Size: 7″ x 20-3/8″ (177 x 518 mm)
• Work Surface: 2-1/8″ x 4″ (54 mm x 101 mm)
• Post Height: 7″ (178 mm)
• Stitch Type: 301
• Needle Guages Available: 3/16″ to 1″ (4.7 mm to 25.4 mm)

* Speed depends on thread, material and operation.
