Applications:

• For sewing medium to heavy-weight materials such as canvas, vinyl, leather, synthetics and various coated, laminated materials.
• For stitching uneven, hollow, tubular and curved articles.
• Designed for stitching such products as boots, shoes, gloves, luggage, handbags, overalls, raincoats, bags, umbrellas, awnings, covers, tarpaulins, tents, sports and camping equipment, wear apparel, outdoor clothing etc.
• Suitable for edge stitching operations, and top stitching.

Features:

• Centra-Lube® semi-automatic lubrication system
• Oil fed take-up
• Safety clutch prevents the hook from being damaged
• Large bobbin allows for longer operation Large vertical axis hook allows for use of thick thread and therefore ornamental stitching can be obtained
• Reverse stitching
• Simple adjustment permits raising and lowering of the center foot which allows for sewing different thicknesses of material

Specifications:

• Speed, Max. (S.P.M.): 2400
• Clearance Under Foot: 25/64″ (10 mm)
• Needle Bar Stroke: 1-5/16″ (33 mm)
• Stitch Length, Max. 4 s.p.i. (6 mm)
• Needle: 135 x 17
• Bobbin:
  • Metal: 15041
  • Pre-wound: S and U
• Hook: 14005
• Bed Size: 7″ x 20-3/8″ (178 x 518 mm)
• Work Surface: 2-1/8″ x 2″ (54 mm x 51 mm)
• Post Height: 7″ (178 mm)
• Stitch Type: 301
